Van Den Hul Frog Gold MC Cartridge & DS Audio Head Shell 001

2 years ago 445

Item Condition: Excellent

Shipping Options: Pickup available and you can audition.,Shipping is included in price.

Suburb or Town: Essendon

State: VIC

Payment Method: Cash / EFT

Reason for selling: Upgraded to other cartridge

Further Information: Van Den Hul Frog Gold - includes a DS Audio HS-001 Duraluminum head shell. Happy to sell without the head shell. Both cartridge and head shell are in full working condition

Cartridge has approx. 400 hours and checked at Carlton Audio Visual.

The van den Hul Frog Gold MC Cartridge is a custom hand-built moving coil cartridge with matched Gold-Wire coils and a Solid Boron Cantilever making it sound even smoother and more refined than the standard Frog - the best cartridge available for the price! The Frog Gold has a 0.65 mV/channel output, matched gold-wire coils and an extra internal support magnet.

Type: Moving coil phono cartridge

Frequency Range 5Hz to 55kHz

Stylus Shape: VDH - IS

Stylus Radii: 2 x 85 Micron

Tracking Force: 1.2 to 1.6 grams

Static Compliance: 35 Micron / mN

Tracking Ability: at 15 mN at 315 Hz 70 - 80 Micron

Output Voltage: at 1 kHz at 5.7 cm/s eff. 0.65 mV RMS

Channel Unbalance: < 0.3 dB

Channel Separation: at 1 kHz/10 kHz >35 / >30 dB

Equivalent Stylus Tip Mass: 0.32 Milligram

Vertical Tracking Angle: 22 Degrees
